ROTORAP RTR 1200 SERIES
Orbital Stretch Wrap Machine

35 seconds/wrap

2 x 30" plastic dispensers

120" Hoop Size

Overview

The Rotorap RTR 1200 orbital stretch wrapper is dedicated to the biggest pallet wrapping of almost any shape. Double hoop propelled by an electric 2200V motor and gearbox. Made for large scale operations and automation process.

https://www.youtube.com/watch?v=zBAAcxeoYV0

The RTR1200 is dedicated to the biggest pallet wrapping of almost any shape.

35 seconds average per wrap
240 or 550 volts - 30 amps
Hand-held remote at forklift’s position or automation
120" hoop size
2 x 30" plastic dispenser
Large load

Indoor or outdoor -10°C to 40°C (10°F to 100°F)
CSA / CULUS approved
One side service doors
Clear or white stretch wrap
40 % pre-stretching on tensioner
3 HP engine

Technical Specifications

Size

48"L x 170"W x 154"H

Hoop size

120"

Maximum pallet size

96"L x 96"H

Film width

30"

Remote

Yes

Drive

Gear to gear

Length of roll

5200'

RPM

Volts

220

Amps

Operating Temp (min/max)

32°F to 100°F

APPLICATIONS

metal cutting

metal painting

cabinets

shipping

forklift

printing

building supplies

aerospace

forage & drilling

mining

Rotorap RTR Series

36" HOOP

RTR 360

74" HOOP

RTR 1000

120" HOOP

RTR 1200
