10" H x 18" W x 61" L - Model T-62 12" H x 22" W x 84" L - Model T-72
25 to 150 ft./min. Speed
42" Max. Conveyor Height
Overview
The Shanklin Model T-62/T-72H Shrink Tunnel is designed for maximum performance with high-speed wrappers, solving a multitude of persistent wrapping challenges. These tough, efficient machines feature a high-speed dual chamber tunnel for optimum shrink capacity, each with independently controllable temperature, air velocity, and flow.
Flexible, Dependable, and Ready to Take On Your Toughest Challenges
Versatile—The most versatile shrink tunnel on the market! Shrinks difficult packages; adjusts easily to handle a variety of applications.
Proven Reliable—Includes long-lasting finstrip heater elements, precision temperature control units, and rugged 3/4 hp blower motors.
Easy to Use—Simply set the variable speed conveyor and adjustable air velocity and temperature controls, and go!
Technical Specifications
Tunnel Passage
10" H x 18" W x 61" L - Model T-62 12" H x 22" W x 84" L - Model T-72
Tunnel Height
38" W overall x 38" H above conveyor - Model T-62 43" W overall x 41" H above conveyor - Model T-72
Conveyor Height
29" minimum, 42" maximum
Conveyor lengths
77", 93", 109" lengths stocked (109" is standard length) - Model T-62 100", 116", 132" lengths stocked (132" is standard length) - Model T-72
Conveyor speed
Variable from 25 to 150 ft./min.
The Perfect Partner
The Shanklin T-62 or T-72H Shrink Tunnel performs seamlessly with our High-Speed Wrappers for a total quality shrink packaging solution.
